Circuit breaker 1P+N 4,5kA
Reference DZ30-10
€3.70
tax incl.
Technical details
- Size 72 x 79 x18 mm
- Indoor / outdoor Interior
- VIN 230V
- Frequency (HZ) 50 Hz
- Working temperature -10º / +50º
- Certifications CE, RoHS, IEC60898-1
- Warranty 3 years
Accessories and related products
- Size 72 x 79 x18 mm
- Indoor / outdoor Interior
- VIN 230V
- Frequency (HZ) 50 Hz
- Working temperature -10º / +50º
- Certifications CE, RoHS, IEC60898-1
- Warranty 3 years
Mini circuit breaker (18 mm), available in 10, 16, 20 and 25 amps.
Effectively protects electrical circuits against overloads and short circuits.
Ideal for the protection of electrical installations in the residential area.
Specifications:
- Number of poles: 1P + N
- Breaking capacity: 4.5 kA
- Curve: C
- Maximum wire section: 10mm²
